Type 1 Charging Port IEC 62196 High Performance EVC1 New Energy Connector for Electric Car

Type 1 Charging Port IEC 62196 High Performance EVC1 New Energy Connector for Electric Car

Tags：EVC  Electric Car, New Energy, IEC62196, EV Connector,  IP55, Type1 Charging Plug, VC,  63A, 240V

Features:
  • Products complies with IEC 62196 standard;
  • Various types for choice, include type 1 AC charging connector
    (according to SAE J1775 and IEC 62196), Type2 DC Charging Connector
    (according to IEC62196), Type2 AC charging connector (according to IEC 62196)
  • Humanized design with a good grasp feel, easy to use.
  • Various accessories available, protection cap include damping cap, metal string cap,etc.
  • The plug and socket termination type is wire crimping.
  • Degree of protection: IP55
ASK A FREE QUOTE

Usage:

Used to connect the electric car and power supply equipment, and then charge the electric car.

Main Technical Specification:

Material:
——Shell: Thermoplastics
——Insulator: Thermoplastic
——Sealing ring: rubber material
——Insulator flame retardant grade: UL94-V0
——Contact: Base material Copper alloy The contact surface is silver plated

Environmental Performance:
——Operating temperature:-30℃～+50℃
——Relative humidity : 98% at40℃
——Degree of protection: IP55 (during charging)

Electrical Performance:

Contact Specification mm Rated Voltage V Rated Current A Applicable Wire mm²
3.6 240 16 2.5
32 6
63 16
2.8 240 Rated for the highest current Power cable with same current specification
1.5 30 2 16AWG

——Insulation resistance: ≥1000MΩ( AC charging connector);

Mechanical Performance:
——Durability
Exceed 10,000 times (Non-charged state)
